Hand-held Ultrasonic Cell Crusher

Power

2.5-250W   Continuously adjustable

4-400W   Continuously adjustable

Capacity（ml）

0.1-150ML(need   to match the probe)

0.1-300ML(need   to match the probe)

Display method

4.3 inch touch   screen

4.3 inch touch   screen

Single ultrasound time

0.1-99.9S

0.1-99.9S

Single gap time

0.1-99.9S

0.1-99.9S

Total time (ultrasound + gap)

1-99H59M59S

1-99H59M59S

Frequency Range

20-30KHz

20-30KHz

Temp. control

0-100℃（Optional low temperature thermostat）

0-100℃（Optional low temperature thermostat）

Alarm function

Time,   overload, no load, over temperature

Time,   overload, no load, over temperature

Probe

Φ3 or Φ5(mm)

Φ5 or Φ6(mm)

Optional probe

Φ2、3、5、6(mm)

Φ2、3、5、6、8(mm)

Data storage

20 group

20 group

Power supply

110V 60Hz

110V 60Hz

Instrument net size (deep * width *   height)

410*225*290（mm）

410*225*290（mm）

Ultrasonic host net weight

12kg

12kg

Ultrasonic host gross weight

15kg

15kg

Host package (length * width * height)

470*305*430（mm）

470*305*430（mm）

Sound insulation box

The transducer   holder weighs approximately 2.5KG

The transducer   holder weighs approximately 2.5KG

Voice alarm and prompt function

yes

yes

Operation password setting

yes

yes
